Removable Hoop Pile Holders

  • Sale
  • Regular price $121.00


The Removable Hoop Pile Holders with Rubber roller allows you to detach the Pile Hoop from the Deck Plate and dock in one easy step.

Please call for a shipping quote if ordering more than one Pile Holder

DESCRIPTION

Removable Hoop Pile Holders

Removable Hoop Pile Holders with Rubber roller is made of 1.5″ Pipe Type. These pile guides are made of 1-1/2″ steel pipe. They can be used with a deck plate and roller assembly. Simply remove the two Hinch Pins and your dock can be pulled in for winter. The hoops are made with 1 1/2″ Schedule 40 Pipe and fit into 2″ Pipe Receivers. They are secured to the Deck Plate with two Hitch Pins.

Deck Plates are made from 1/4″ High-Strength Steel then hot-dipped galvanized.

The complete assembly (Removable Hoop, Hinch Pins, Deck Plate and Roller Assembly) Is included in the purchase.

PLEASE NOTE: These are specifically designed to fit certain sizes, they do not stretch or bend. Please make sure you are ordering the correct size. DOUBLE CHECK the OUTSIDE DIAMETER of your piling by measuring the circumference of your piling and divide by 3.14.

Please call for a shipping quote if ordering more than one Pile Holder.

ADDITIONAL INFORMATION



SKU Product
PH-H8
8" Pile Hoop, Hoop Only
PH-H8R 8" Hoop Pile Assembly Complete
PH-H10 10" Pile Hoop, Hoop Only
PH-H10R 10" Hoop Pile Assembly Complete
PH-H12 12" Pile Hoop, Hoop Only
PH-H12R 12" Hoop Pile Assembly Complete
PH-H14 14" Pile Hoop, Hoop Only
PH-H14R 14" Hoop Pile Assembly Complete
PH-H16 16" Hoop Pile , Hoop Only
PH-H16R 16" Hoop Pile Assembly Complete
PH-H18 18" Hoop Pile , Hoop Only
Ph-H18R 18" Hoop Pile Assembly Complete



Weight 8 - 44 lbs.
Dimensions N/A
Size

8 inch, 10 inch, 12 inch, 14 inch, 16 inch, 18 inch

Part

Complete Assembly, Hoop Only, Deck Plate Only, Roller Assembly Only
