Air Tanks by Ace Roto-Mold

  • Sale
  • Regular price $499.00


Boat Lift / Air Tank Floats General Information

  • Molded-in mounting holes in the top of the drum
  • A large molded-in hole in the bottom for water intake and exhaust
  • Threaded inserts for commercial fittings
  • Heavy 3/8″ wall thickness for structural strength
  • The top has molded-in grooves for mounting to lift
  • Now available with a square bottom

When looking at tank sizes, the first number is the height, the second number is the width, and the third number is the length.

DESCRIPTION

Air tanks feature a molded hole in the bottom of the for water to exhaust and intake.  Each one has molded-in grooves and slots for secure attachment to a frame. Because submerging requires filling them with water causing them to sink when it’s time to re-float, use 3 to 5 psi of air pressure, and the water exits and begin to rise.

Building your boat lift with air tanks by Ace Roto-Mold that have a wall thickness of .375″ offers a lot of lifting capability.

Eight different sizes, in the round and square bottom designs. Threaded inserts are ready for fitting industrial fasteners. Slots and molded-in grooves at the top of each tank make attachment to a frame easy.

ADDITIONAL INFORMATION

Weight N/A
Dimensions N/A
Model

#AT2630-60, #AT3030-72SQ, #AT3030-90, #AT3030-90SQ, #AT3240-108, #AT3240-108SQ, #AT3240-144SQ, #AT4848-20SQ



  • Molded-in mounting holes on the top of the drum
  • A large molded-in hole in the bottom for water intake and exhaust
  • Threaded inserts for commercial fittings
  • Heavy 3/8" wall thickness for structural strength
  • The top has molded-in grooves for mounting to lift
  • Now available with a square bottom







BOAT LIFT/AIR TANK FLOATS
Model #
Size
(Height x Width x Length)
Wall
Thickness
Drum Buoy
(in lbs.)
Bottom
Specs
AT4848-20SQ
48" x 48" x 20"
.375"
1304
Square
View
AT2630-60
26" x 30" x 60"
.375"
1000
Round
View
AT3030-72SQ
30" x 30" x 72"
.375"
2150
Square
View
AT3030-90
30" x 30" x 90"
.375"
2000
Round
View
AT3030-90SQ
30" x 30" x 90"
.375"
2600
Square
View
AT3240-108
32" x 40" x 108"
.375"
3700
Round
View
AT3240-108SQ
32" x 40" x 108"
.375"
4500
Square
View
AT3240-144SQ
32" x 40" x 144"
.375"
6600
Square
View
